IntelliCenter Control System User’s Guide
10 |
Nocturnal Cooling Set Point
Temperature control for Heat Pump
or Solar: If using a heat pump, use the
Cooling Set Point temperature or solar
heat control buttons displayed on the
Pool and/or Spa screen to adjust the
nighttime temperature of the pool/spa
water. See page 74.
Schedules (Heat Source and Set Temperature) See page 20: See Schedules to
schedule the pool/spa pump to turn on at a specific time to pre-heat the pool or
spa water. From the Schedules Weekly or One Time Only option, select Heat Source
and select a heat source, then set the Set Temperature settings.
Note: If the Heat Mode is set to Off, the Heating Set Point setting on the Pool
screen is not displayed. Tap the Heat Mode button to display the Select Heat
Source screen. Note: The Home screen displays a Blue badge over the Pool icon
with the current pool water temperature.
Pool Spa Features Lights
Air Temp 65° F
Schedule Usage Chemistry Status
3 3
8:00 A.M.
6.50
0
4
78
°
Pool
Pool Pump Button (Override Freeze Protect)
Solar Heater: Nocturnal (nighttime) feature provides automatic cooling during
night time hours for pools that overheat in hot climates to circulate the warmer
pool water to the collector panels when the collector temperature and the pool
temperature is hotter than the high limit setting. This process cools the pool water
over time. Note: This feature is also used for the UltraTemp heat pump, Hybrid
Heater and a Heat Pump. See page 74.
Pool
Temp
77
Pool
Pool Filter Pump
Off
Heat Mode
Freeze Protection Override: The pool pump can be manually turned on to override
the Freeze protection. This also applies if a schedule is running. To assign freeze
protection to a circuit. See page 59 for more information.
Pool
Temp
40°
Pool (schedule on in freeze)
Pool Pump
Off
Heat Mode
(press manual ON)
Pool
Temp
40°
Pool (manually turned on in freeze)
Pool Pump
Off
Heat Mode
(press manual ON)
