Pentair INTELLICENTER User Manual

IntelliCenter Control System User’s Guide
| 23
Scheduled One Time Only
Heat Source
Stop Time
Start Time
8:00
Circuit
Pool
Fri, Jan, 12 2018
5:00
Gas
_
Set Temperature
+
77
Scheduled One Time Only
Heat Source
Stop Time
Start Time
8:00
Circuit
Pool
Fri, Jan, 12 2018
5:00
Gas
_
Set Temperature
+
77
Schedule - One Time Only (Continued)
Start Time (Manual): Set the
start time (am/pm) for the Weekly
schedule.
Stop Time (Manual): Set the stop time
(am/pm) for the Weekly schedule. see
page 24.
Duration: Stop time duration: The
equivalent time left after the start time
is established (e.g. 1:00 AM to 9:00
AM. The system clock calculates the
duration between the start and stop
time which is 8 hours. 24 Hrs. duration
is display when the Start/Stop time is
set to 8 AM to 8 PM. Note: To offset
Sunrise and Sunset start time, see
page 24.
Manual Sunrise Sunset
Select Start Time
8h 00m:1 00AM
Manual Sunrise Sunset
Select Stop Time
8h 00m:9 00AM
Duration: Start time duration: The
equivalent time left after the start time
is established (e.g. 1:00 AM to 9:00
AM. The system clock calculates the
duration between the start and stop
time which is 8 hours. 24 Hrs. duration
is display when the Start/Stop time
is set to 8 AM to 8 PM. Note: To offset
Sunrise and Sunset start time.
Heat Source: Tap Heat Source and
select: Off, Heater, Solar Only, or Solar
Preferred. Heat Pump Only, Heat Pump
Preferred. To create a heat source
go to Settings > Advanced System
Configuration > Installation Setup
> Heaters, See page 72 for more
information.
Set Temperature: Tap the plus or
minus button to set the Heat Source set
point temperature from 40° F
to 104° F.

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
