Pfaff creative icon User Manual

Introduction
2 Introduction
Machine Overview
Front
1. Lid
2. Thread tension discs
3. Thread take-up lever
4. Threading slot
5. Thread cutter
6. LED light
7. Needle plate
8. Bobbin cover
9. Bobbin cover release button
10. Base plate
11. Function buttons, see Function Buttons, page 15 for
detailed description
12. Knee lifter socket
13. Save
14. Mode switch
15. Home
16. Multi-touch screen
17. Bobbin winding thread slot
18. Auxiliary spool pin
19. Main spool pin
20. Telescopic thread guide
1
2
3
4
5
6
7
8
9
10
6
11
6
12
13
14
15
16
17
18
19
20
11

Pfaff creative icon Specifications

General

Stitch Width	9 mm
Needle Positions	37
Lighting	LED
USB Port	Yes
Automatic Thread Cutter	Yes
Built-in Memory	Yes
Maximum Sewing Speed	1050 stitches per minute
Connectivity	WiFi, USB
Needle Threader	Fully Automatic
Bobbin Winding	Separate bobbin winding motor
Screen	10.1" Full Color Touch Screen
Weight	15.6 kg
