Pfaff creative icon User Manual

Introduction
Needle Area
1. Automatic needle threader, see Using the Automatic
Needle Threader, page 38
2. Needle bar with needle clamp screw
3. Needle thread guide
4. Presser foot bar
5. IDT™
6. Presser foot ankle
7. Presser foot
Right Side
1. Handwheel
2. Speaker
3. Built-in USB ports
4. Speed control lever
5. ON/OFF switch, sockets for power cord and foot
control. See Connect the Power Cord and Foot
Control, page 26.
Rear
1. Handle
2. Accessory socket
3. Free arm
4. Embroidery unit socket
1
2
3
4
5
6
7
1
5
4
3
2
1
2
3
4
12

Pfaff creative icon Specifications

General

Stitch Width	9 mm
Needle Positions	37
Lighting	LED
USB Port	Yes
Automatic Thread Cutter	Yes
Built-in Memory	Yes
Maximum Sewing Speed	1050 stitches per minute
Connectivity	WiFi, USB
Needle Threader	Fully Automatic
Bobbin Winding	Separate bobbin winding motor
Screen	10.1" Full Color Touch Screen
Weight	15.6 kg
