Pfaff creative icon User Manual

Embroidery Stitch-Out
Pop-up Messages in Embroidery
Stitch-Out
The Embroidery Arm Needs to Calibrate
When the embroidery unit is attached, a pop-up
message will appear and inform you to slide off the
hoop and clear the machine area for calibrating the
embroidery arm. You will also be reminded to
disengage the IDT™ system and attach a suitable
embroidery foot.
It is very important to remove the hoop, otherwise
the hoop or the embroidery unit may be damaged
while calibrating.
Attach Hoop
If the hoop attached to the machine does not match the
hoop that is selected and displayed on the screen, the
machine will not embroider. You must change the hoop
to the one displayed on the screen or return to
Embroidery Edit and select the hoop to match the
attached hoop.
The hoop needs to be inserted properly for the machine
to detect it. Slide the hoop connector into the hoop
attachment from front to back until it clicks into place.
146

Pfaff creative icon Specifications

General

Stitch Width	9 mm
Needle Positions	37
Lighting	LED
USB Port	Yes
Automatic Thread Cutter	Yes
Built-in Memory	Yes
Maximum Sewing Speed	1050 stitches per minute
Connectivity	WiFi, USB
Needle Threader	Fully Automatic
Bobbin Winding	Separate bobbin winding motor
Screen	10.1" Full Color Touch Screen
Weight	15.6 kg
