Maintenance
using with you. If you have a stitch out that shows the
problem, please bring that as well. A sewing sample will
often give better information than words and help your
technician diagnose the problem.
Non-Original Parts and Accessories
The warranty does not cover any defect or damage
caused by use of non-original accessories or parts.
Technical specification
creative icon™ machine
Rated voltage 100–120V/200–240V, 50–60Hz
Nominal consumption
<100W
Light LED lamps
Sewing speed 1050 stitches/minute maximum
Foot control model
FR5
Safety class
II
WiFi module:
Frequency
Transmitting power
Receiver sensitivity
2.4GHz band 802.11 b/g/n
+17dBm
-97dBm
Net weight (kg), machine only
Net weight (kg), embroidery unit
14.5
4.1
Machine dimensions:
Length (mm)
Width (mm)
Height (mm)
590
220
400
• The technical specifications and this user’s guide can
be changed without prior notice.
209

Pfaff creative icon Specifications

General

Stitch Width	9 mm
Needle Positions	37
Lighting	LED
USB Port	Yes
Automatic Thread Cutter	Yes
Built-in Memory	Yes
Maximum Sewing Speed	1050 stitches per minute
Connectivity	WiFi, USB
Needle Threader	Fully Automatic
Bobbin Winding	Separate bobbin winding motor
Screen	10.1" Full Color Touch Screen
Weight	15.6 kg
