10
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
10.53
4. Use a commercially available caliper piston pliers to
extract the pistons from the caliper.
IMPORTANT
Do not remove the caliper pistons with a standard
pliers. The piston sealing surfaces will become
damaged if a standard pliers is used.
5. Once the pistons are removed, use a pick to carefully
remove the square O-rings
e
from the caliper. O-
rings should be replaced during caliper service.
6. Clean the caliper body, pistons and retaining bracket
r
with brake cleaner or alcohol.
NOTICE
Be sure to clean seal grooves in caliper body.
BRAKE SYSTEM
To Next Page
