9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
11.15
REAR CENTER CONSOLE
q
Center Console Top
u
Compartment Plug
w
Plastic Push Rivet
i
Center Console Cover Fastener
22 in-lbs (2.5 Nm)
e
Rear Center Console
o
Center Console Cover
r
Storage Bin
a
Inner Center Console Cover
t
Cup Holder
s
Center Console Seal
y
Rubber Grommet
BODY / FRAME
