INSTALLATION
1. If removed, install bracket to subwoofer using three
fasteners. Torque fasteners to specification.
TORQUE
Subwoofer / Amp Bracket Fasteners:
30 in-lbs (4 Nm)
2. Install bracket (with subwoofer) to dash support
structure using four fasteners
f
. Torque fasteners to
specification.
TORQUE
Subwoofer / Amp Bracket Fasteners:
30 in-lbs (4 Nm)
3. Install two fasteners
d
through dash support
brackets into subwoofer. Torque fasteners to
specification.
TORQUE
Subwoofer Mounting Fasteners:
30 in-lbs (4 Nm)
4. Install amp to bracket using four fasteners
s
. Torque
fasteners to specification.
NOTICE
Ensure amp connector is on LH side as shown.
TORQUE
Amplifier Mounting Fasteners:
30 in-lbs (4 Nm)
