13
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
13.69
2. Route antenna cable through hole in ROPS B-pillar
bracket, then install clamshell cover to bracket using
two mounting fasteners. Torque fasteners, then close
cover.
TORQUE
V2V Mounting Fastener:
40 in-lbs (4.5 Nm)
3. Join connector from antenna to connector on RIDE
COMMAND harness. Ensure harness is routed and
secured to ROPS using two panduit straps.
FACTORY-INSTALLED OPTIONS
