Gui setting Description Remote command
"Screen Colors (Print)" Selects the current screen colors for the
printout. The background is always printed in
white and the grid in black.
HCOP:CMAP:DEF1
"Optimized Colors" Selects an optimized color setting for the
printout to improve the visibility of the colors
(default setting). Trace 1 is blue, trace 2
black, trace 3 green, and the markers are
turquoise. The background is always printed
in white and the grid in black.
HCOP:CMAP:DEF2
"Screen Colors
(Screenshot)"
Selects the current screen colors without any
changes for a screenshot.
HCOP:CMAP:DEF4
HCOPy:CMAP<it>:HSL <hue>, <sat>, <lum>
This command selects the color for various screen elements in print jobs.
Suffix:
<it>
.
Selects the item for which the color scheme is to be defined.
Parameters:
<hue> hue
tint
Range: 0 to 1
<sat> sat
saturation
Range: 0 to 1
<lum> lum
brightness
Range: 0 to 1
Example:
HCOP:CMAP2:HSL 0.3,0.8,1.0
Changes the grid color
Manual operation: See "Defining User-specific Colors" on page 224
HCOPy:CMAP<it>:PDEFined <Color>
This command selects a predefined color for various screen elements in print jobs.
Suffix:
<it>
.
1..n
Selects the item for which the color scheme is to be defined.
Parameters:
<Color> BLACk | BLUE | BROWn | GREen | CYAN | RED | MAGenta |
YELLow | WHITe | DGRay | LGRay | LBLue | LGReen | LCYan |
LRED | LMAGenta
Example:
HCOP:CMAP2:PDEF GRE
