10.2.8 Bit Rate
Register (BRR)
Table 10.5 Maximum
Bit Rate for Each
Frequency
(Asynchronous Mode)
350 Table amended
Setting
OSC (MHz)
φ
φφ
φ (MHz)
Maximum Bit Rate
(bit/s) n N
0.0384
*
0.0192 600 0 0
2 1 31250 0 0
2.4576 1.2288 38400 0 0
4 2 62500 0 0
10 5 156250 0 0
16 8 250000 0 0
20 10 312500 0 0
10.2.8 Bit Rate
Register (BRR)
Table 10.6 Examples
of BRR Settings for
Various Bit Rates
(Synchronous
Mode) (2)
352 Table amended
φ
10 MHz
Bit Rate
(bit/s)
n N Error
200 0 12499 0
250 2 624 0
300 0 8332 0
500 0 4999 0
1K 0 2499 0
2.5K 0 999 0
5K 0 499 0
10K 0 249 0
25K 0 99 0
50K 0 49 0
100K 0 24 0
250K 0 9 0
500K 0 4 0
1M — — —
Notes amended
Notes: The value set in BRR is given by the following equation:
φ
N =
(
4 • 2
2n
• B)
– 1
where B: Bit rate (bit/s)
N: Baud rate generator BRR setting (0 ≤ N ≤ 255)
φ: System clock frequency
n: Baud rate generator input clock number (n = 0, 2, or 3)
(The relation between n and the clock is shown in table 10.7.)
