Renesas H8 Series Hardware Manual

Section 1 Overview
Rev. 7.00 Mar 10, 2005 page 21 of 652
REJ09B0042-0700
Pin No.
Type Symbol
FP-80A
TFP-80C
FP-80B TLP-85V
Pad
No.
*
1
Pad
No.
*
2
Pad
No.
*
3
I/O Name and Functions
Interrupt
pins
WKP
7
to
WKP
0
20 to 13 22 to 15
H1, J1,
H3, G1,
H2, G2,
F2, G3
21 to
14
22 to
15
20 to
13
Input
Wakeup interrupt
request 7 to 0: These are
input pins for rising or
falling-edge-sensitive
external interrupts.
Timer
pins
AEVL
AEVH
68
67
70
69
A6
B7
69
68
70
69
68
67
Input Asynchronous event
counter event input:
This is an event input pin
for input to the
asynchronous event
counter.
TMIC 76 78 B3 77 78 76 Input Timer C event input:
This is an event input pin
for input to the timer C
counter.
UD 61 63 A9 62 63 61 Input
Timer C up/down select:
This pin selects up- or
down-counting for the
timer C counter. The
counter operates as a
down-counter when this
pin is high, and as an up-
counter when low.
TMIF5 7 D1 565InputTimer F event input:
This is an event input pin
for input to the timer F
counter.
TMOFL62 64 A8 636462OutputTimer FL output: This is
an output pin for
waveforms generated by
the timer FL output
compare function.
TMOFH63 65 B9 646563Output
Timer FH output: This is
an output pin for
waveforms generated by
the timer FH output
compare function.
TMIG2 4 C1 232Input
Timer G capture input:
This is an input pin for
timer G input capture.
