Section 1 Overview
Rev. 7.00 Mar 10, 2005 page 22 of 652
REJ09B0042-0700
Pin No.
Type Symbol
FP-80A
TFP-80C
FP-80B TLP-85V
Pad
No.
*
1
Pad
No.
*
2
Pad
No.
*
3
I/O Name and Functions
10-bit
PWM pin
PWM1
PWM2
54
55
56
57
E10
D9
55
56
56
57
54
55
Output
10-bit PWM output:
These are output pins for
waveforms generated by
the channel 1 and 2 10-bit
PWMs.
I/O ports P1
7
P1
6
P1
4
P1
3
5
4
3
2
7
6
5
4
D1
C2
B2
C1
5
4
3
2
6
5
4
3
5
4
3
2
I/O Port 1: This is a 4-bit I/O
port. Input or output can
be designated for each bit
by means of port control
register 1 (PCR1).
Note that the H8/38124
Group is not equipped
with a pin 16.
P3
7
to
P3
0
68 to 61 70 to 63
A6, B7
C7, A7
B8, B9
A8, A9
69 to
62
70 to
63
68 to
61
I/O
Port 3: This is an 8-bit I/O
port. Input or output can
be designated for each bit
by means of port control
register 3 (PCR3).
If the on-chip emulator is
used, pins 33, 34, and 35
are reserved for the
emulator and not
available to the user.
P4
3
72 74 C5 73 74 72 Input
Port 4 (bit 3): This is a 1-
bit input port.
P4
2
to
P4
0
71 to 69 73 to 71
B6
B5
C6
72 to
70
73 to
71
71 to
69
I/O
Port 4 (bits 2 to 0): This
is a 3-bit I/O port. Input or
output can be designated
for each bit by means of
port control register 4
(PCR4).
P5
7
to
P5
0
20 to 13 22 to 15 H1, J1
H3, G1
H2, G2
F1, G3
21 to
14
22 to
15
20 to
13
I/O Port 5: This is an 8-bit I/O
port. Input or output can
be designated for each bit
by means of port control
register 5 (PCR5).
P6
7
to
P6
0
28 to 21 30 to 23
K5, J4
H4, K4
J3, J2
K3, K2
29 to
22
30 to
23
28 to
21
I/O
Port 6: This is an 8-bit I/O
port. Input or output can
be designated for each bit
by means of port control
register 6 (PCR6).
To Next Page
