Section 1 Overview
Rev. 7.00 Mar 10, 2005 page 23 of 652
REJ09B0042-0700
Pin No.
Type Symbol
FP-80A
TFP-80C
FP-80B TLP-85V
Pad
No.
*
1
Pad
No.
*
2
Pad
No.
*
3
I/O Name and Functions
I/O ports
P7
7
to
P7
0
36 to 29 38 to 41
J8, J7
K6, H7
H6, J7
H6, J5
J6, H5
37 to
30
38 to
31
36 to
29
I/O
Port 7: This is an 8-bit I/O
port. Input or output can
be designated for each bit
by means of port control
register 7 (PCR7).
P8
7
to
P8
0
44 to 37 46 to 39 H9, J9
H10, J10
K8, K9
H8, K7
45 to
38
46 to
39
44 to
37
I/O Port 8: This is an 8-bit I/O
port. Input or output can
be designated for each bit
by means of port control
register 8 (PCR8).
P9
5
to
P9
0
59 to 54 61 to 56 B10, C8
D10, C9
D9, E10
60 to
55
61 to
56
59 to
54
Output Port 9: This is a 6-bit
output port. If the on-chip
emulator is used, pin 95 is
reserved for the emulator
and not available to the
user. In the case of the
F-ZTAT version, pin 95
should not be left open in
the user mode, and
should instead be pulled
up to high level.
PA
3
to
PA
0
45 to 48 47 to 50 G10
G8
G9
F10
46 to
49
47 to
50
45 to
48
I/O Port A: This is a 4-bit I/O
port. Input or output can
be designated for each bit
by means of port control
register A (PCRA).
PB
7
to
PB
0
80 to 73
2, 1,
80 to 75
A3, A2
C3, A4
B3, B4
A5, C4
81 to
74
1,
81 to
75
80 to
73
Input
Port B: This is an 8-bit
input port.
RXD
32
70 72 B5 71 72 70 Input SCI3 receive data input:
This is the SCI3 data
input pin.
Serial
communi-
cation
(SCI)
TXD
32
71 73 B6 72 73 71 Output
SCI3 transmit data
output: This is the SCI3
data output pin.
SCK
32
69 71 C6 70 71 69 I/O SCI3 clock I/O: This is
the SCI3 clock I/O pin.
A/D
converter
AN
7
to
AN
0
80 to 73 2, 1,
80 to 75
A3, A2
C3, A4
B3, B4
A5, C4
81 to
74
1,
81 to
75
80 to
73
Input Analog input channels 7
to 0: These are analog
data input channels to the
A/D converte.
