Rexroth Indramat ECODRIVE03 Series User Manual

4-72 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
Basic connection of motor power, holding brake and
motor temperature monitoring
AP5107F1.FH7
3 4 1 2
F G
AC-Motor
M
3
A1 A2 A3
A B C D
X6
E H
5 6
TM+ TM- BR+ BR-
U
B
0V B
24V Ext
0V Ext
DKC
XE1
X5
7
8
0V B UB
24V
XS1
Temperature
dependent resistance
Holding
brake
U
Fig. 4-106: Connection of motor cable, holding brake and temperature monitor
for motors with connectors
AP5125F1.FH7
3
4 1 2
AC-Motor
M
3
A1 A2 A3
U1
X6
5 6
TM+ TM- BR+ BR- U
B
0V
B
24V Ext
0V Ext
DKC
XE1
X5
7
8
0V
B
U
B
24V
XS1
V1 W1
X1 X2
T1 T2
U
BR- BR+
Temperature
dependent resistance
Holding
brake
Fig. 4-107: Connection of motor cable, holding brake and temperature monitor
for motors with connector box
Note: The cable designations and all details on making cables are
outlined in the cable or motor document.
