Rexroth Indramat ECODRIVE03 Series User Manual

ECODRIVE03 Drive Controllers ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 4-71
V 04 CD:8/6.6X tsniaga 7/5.6X ta egatlov .xam
current consumption at X6.5 and needed supply
voltage:
see "Technical data"
brake in the motor
manual
max. allowed current load when looping through
brake supply over X6.5/6 to X6.7/8:
DC 10 A
wire cross section:
min. 1 mm ²
for looping through: min. 2.5 mm ²
Voltage resistance of single wire to
ground
> 750 V
(e.g.: litz wires - H07)
wire routing
parallel if possible
(twisted)
max. inductance between 24 V source
and X6
100 µH
(equals about 2 x 75 m)
CAUTION
Risk of damage!
 Risk of damage by increased transition resistance in
the case of strong mechanical inuence at the test
tap.
Motor holding brake
The controller controls the holding brake.
Supply voltage, current consumption, linking, separating time, holding
torque, etc. see motor manual.
Voltage connection for brakes
on DKC:
Wire
voltage connection for brake:
Controlling the motor holding
brake:
Technical data
Motor holding brake:
