ECODRIVE03 Drive Controllers ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 4-77
Input voltage
Signal amplitude nominal:
(referencing unit ground)
High
Low
min.
> 2.4 V
0 V
max.
5 V
< 0,8 V
zHk 002ycneuqerf timiL
R 021ecnatsiser tupnI
Fig. 4-117: Features of the dierential input (Square-wave encoder)
See "G2Sin+ (A+), G2Sin- (A-):"
See "G2Sin+ (A+), G2Sin- (A-):"
Returning encoder supply to amplier so that encoder cable can be
regulated and 5V are pending at the encoder independent of cable length.
Features of the encoder output amplier stage G2_5V:
V 5:egatlov tuptuO
DC
Am 003:tnerruc tuptuo .xam
Fig. 4-118: Features of the encoder output amplier stage
Square-wave encoder
G2Ref+ (R+), G2Ref- (R-):
G2Cos+ (B+), G2Cos- (B-):
G2_5VSen, G2_0VSen:
G2_5V:
