Rexroth Indramat ECODRIVE03 Series User Manual

4-80 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
2. Without sensor connection in the encoder lead
0
5
10
15
20
25
30
35
40
45
50
0 0,05 0,1 0,15 0,2 0,25 0,3
I [A]
L [m]
A = 0,25 mm ² A = 0,5 mm ² A = 1,0 mm ²
L: cable length
I: current
A: wire cross sections
Fig. 4-121: Without sensor connection
Measuring Systems Connections
See page 1-4: "An Overview of Measuring Systems Supported “.
