610-3.**CKD 30EVIRDOCEsrellortnoC evirD 30EVIRDOCE 5-31
Signal allocation to the actual position value
Signal allocation (X4) signal designation signal form actual position value
(with default setting)
amplitude-modulated signal
G1Sin+(S3)
G1Sin- (S1)
G1Cos+(S4)
G1Cos- (S2)
Resolver increasing
Fig. 5-51: Signal allocation to the actual position value
Note: default setting:
=> see functional rmware description: "Motor Encoder"
(Encoder 1).
Connecting the Measuring System
See page 1-4 "An Overview of Measuring Systems Supported".
