Rexroth Indramat ECODRIVE03 Series User Manual

12-2 srellortnoC evirD 30EVIRDOCEtenibaC lortnoC eht gnitcurtsnoC
0
10
20
30
40
50
60
70
80
0123 456
I [A]
Pv [W]
P
V
: Power dissipation
I: Current (Sine threshold value)
Fig. 12-2: Determining power dissipation in the control cabinet for each drive
controller DKC**.3-016-7-FW without braking resistor power with
4 kHz
0
10
20
30
40
50
60
70
80
0 1 2 3 4 5
I [A]
Pv [W]
P
V
: Power dissipation
I: Current (Sine threshold value)
Fig. 12-3: Determining power dissipation in the control cabinet for each drive
controller DKC**.3-016-7-FW without braking resistor power with
8 kHz
DKC**.3-016-7-FW
4 kHz
DKC**.3-016-7-FW
8 kHz
