Rexroth Indramat ECODRIVE03 Series User Manual

tenibaC lortnoC eht gnitcurtsnoCsrellortnoC evirD 30EVIRDOCE 12-3
0
40
80
120
160
200
048 12 16
I [A]
Pv [W]
P
V
: Power dissipation
I: Current (Sine threshold value)
Fig. 12-4: Determining power dissipation in the control cabinet for each drive
controller DKC**.3-040-7-FW without braking resistor power with
4 kHz
0
40
80
120
160
200
0 2,5 5 7,5 10 12,5
I [A]
Pv [W]
P
V
: Power dissipation
I: Current (Sine threshold value)
Fig. 12-5: Determining power dissipation in the control cabinet for each drive
controller DKC**.3-040-7-FW without braking resistor power with
8 kHz
DKC**.3-040-7-FW
4 kHz
DKC**.3-040-7-FW
8 kHz
