4-16 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
Output current characteristic curves for servo
applications ( acceleration times < 400 ms)
Static prole illustrated:
DG0003F1.FH7
I
PEAK
I
CONT
I
PEAK1
I
PEAK2(4kHz)
I
CONT1(8kHz)
I
PEAK2(8kHz)
I
CONT2(8kHz)
I
CONT1(4kHz)
I
CONT2(4kHz)
f1 = 4kHz
f2 = 8kHz
Fig. 4-16: Output current characteristic curves for servo applications
See also the table with electric data page 4-6 onward.
