4-24 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
Arranging the Group supply with DC bus connection
Note: Increase the available continuous power in the common DC
bus for the devices DKC**.3-040.
See also page 16-5 Calculating the allowed continuous
braking resistor and DC bus power.
Ap5110f1.fh7
DKC**.3
K1
3
3
3
3
-040
DKC**.3
-040
Fig. 4-24: Group supply with DC bus connection
Note: In addition to the illustrated connections of the drive controller
at the DC bus, the following connections must be wired as
well:
• Bb contact
• control voltage supply
