ECODRIVE03 Drive Controllers ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 4-51
RS485 interface
The RS485 interface is used for programming, parameterization and
diagnoses at start up and service.
It makes possible:
• the implementation of a serial bus with up to 31 participants connected
via a two-wire cable (half duplex mode)
• A transmission length of up to 500 m
• Transmission rates of 9600/19200 baud
• The use of a centrally PC supported visualization unit
Using an RS485 enables the commissioning of several DKCs with
DriveTop without changing the interface cables is possible.
The following options for working with RS485 are available
• RS232/RS485
converter between PC and drives
• RS485 plug-in card in PC
Please contact your PC supplier to help nd solutions.
Note: Details are listed in "Electromagnetic compatibility (EMC) and
control systems", doc. Type DOK-GENERL-EMV********-PRxx.
Installation notes for RS485 –
cables
