4-52 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
Connection for RS485 interface:
Ap5316f1.fh7
4
5
7
12
1
2
3
1
2
3
X1
X2
4
5
7
12
1
2
3
1
2
3
X1
X2
PC
1)
RS 485
1)
)3)3
A B
0V
390
150
390
390
150
390
RS232/RS485 converter
or PC plug- in card
INS0619
INK0572
to further
devices
10 10
INS0619
X2
2. DKC
X2
1. DKC
2)
RS485+
RS485-
0V
+5V
0V
2)
RS485+
RS485-
0V
+5V
0V
1): Connect outer screen to device potential on PC side and converter side
(strain relief of metallic connector case)
2) Connect the metallic connector case with the device potential using the
fastening screws of the connector
3) If the drive controller is tted as the last participant of a RS485 bus,
activate the bus termination. => Shift switch to "I".
Fig. 4-62: Connection example of RS485 interface
 See also the rmware functional description: "Serial Communications"
