6.4.14 CONFIGURATION OF CARRIER ENVELOPE NOISE DETECTOR
The position of switch SW8-1 determines if the carrier envelope noise detector is enabled. Placing
SW8-1 in the ON position enables the carrier envelope noise detector. Placing SW8-1 in the OFF
position disables the carrier envelope noise detector.
6.4.15 CONFIGURATION OF TX TRIP SHIFT DIRECTION
The position of switch SW8-2 determines trip shift direction as shown in Table 6-16.
Table 6-16. TX Trip Polarity
SW8-2 ON TX Guard = shift down
TX Trip = shift up
OFF (default) TX Guard = shift up
TX Trip = shift down
6.4.16 CONFIGURATION OF TRIPIN_1/TRIPIN_2 SOLID-STATE CONTACTS
The position of switches SW8-3 and SW8-4 determine the solid-state input configuration of Tripin 1
and Tripin 2 shown in Table 6-17.
Table 6-17. Solid State Input Configuration
SW8-3 ON Tripin 1 is normally energized
OFF Tripin 1 is normally de-energized
SW8-4 ON Tripin 2 is normally energized
OFF Tripin 2 is normally de-energized
6.4.17 CONFIGURATION OF RX TRIP SHIFT DIRECTION
The position of switch SW8-5 determines trip shift direction as shown in Table 6-18.
Table 6-18. RX Trip Polarity
SW8-5 ON RX Guard = shift down
RX Trip = shift up
OFF (default) RX Guard = shift up
RX Trip = shift down
