17.4.2 CONTROLS AND INDICATORS
Figure 17-12 shows the location of all controls and indicators on the Solid State Input/Output I/O
module. These controls and indicators are described in Table 17-7. Terminal blocks TB1 and TB2 are
accessible with the Solid-State Input/Output I/O module installed in the chassis. Jumpers J4 and J5 are
only accessible when the module is removed from the chassis or is on a card extender.
Table 17-7. Controls and indicators, Solid-State Input/Output I/O module
Component
Designator
Name/
Description
Function
J4 Jumper Selects 48V or 125V operation
J5 Jumper Selects 48V or 125V operation
TB1 Terminal block Provides connections to line coupling equipment.
TB2 Terminal block Provides connections to line coupling equipment.
