RFL Electronics 9780 - Table 18-4. Replaceable Parts, RFL 9780 Skewed Hybrid Module

RFL 9780 RFL Electronics Inc.
September 8, 2001 18-13 (973) 334-3100
Table 18-4. Replaceable parts, RFL 9780 Skewed Hybrid Module
Assembly No. 106625-1 and -2
Circuit Symbol
(Figs. 18-6 & 18-7)
Description Part Number
MISCELLANEOUS COMPONENTS
CR1 Suppressor, transient, bidirectional. 75V 101473
F1 Fuse, SLO-BLO, 10A, 32V, 3AG 10758
J1-J3 Connector, header, single, 3CKT 32802 3
L1 Transformer, hybrid, 50 ohm, XMIT
106625-1 55766
106625-2 55865
L2
Transformer, hybrid, 50 ohm, XMIT
106625-1 55766
106625-2 55865
P1 Connector, JK, male, 64 contact, DIN 98457
R1-3
Resistor, fixed composition, 100Ω, 5%, 1W
1009 182
R4
Resistor, metal film, variable, 100Ω, 10%, 2W
44356
R5 Resistor, wirewound, 50Ω, 5%, 2.5W 1100 747
R6 Resistor, wirewound, 50Ω, 5%, 5W 1100 748
R7, 8 Resistor, wirewound, 12Ω, 5%, 2.5W 1100 745
R9, 10, 11 Resistor, metal film, precision, 12.1Ω, 1%, 1/2W 1510 2109
SW1 Switch, rotary, 1 deck, 6 position 44357
TP3, 4 Test point terminal, orange 98441 3
TP5 Test point, green 38116 5
TP6 Test point, yellow 38116 8
TP7 Test point, red 38116 2
TP8 Test point, white 38116 1
