RFL 9780 RFL Electronics Inc.
September 8, 2001 18-5 (973) 334-3100
Table 18-1. Replaceable parts, RFL 9780 X-Hybrid module. Assembly No. 106630-1 and -2.
Component
Designator
Name/Description Function
J1 Jumper Selects internal or external balancing network (A = internal, B = external)
TP3 Test point Line High (orange)
TP4 Test point Line Low (orange)
TP5 Test point Receive High (green)
TP6 Test point Receive low (yellow)
TP7 Test point Send High (red)
TP8 Test point Send Low (white)
18.2.3.1 SELECTING THE BALANCING NETWORK
Jumper J1 is used to select either the internal (50 Ohm resistive) balancing impedance or an external, user
supplied, balancing impedance. Placing the jumper in the A position selects the internal impedance.
Selecting the B position selects the external impedance.
Table 18-2. Replaceable parts, RFL 9780 X-Hybrid module. Assembly No. 106630-1 and -2.
Circuit Symbol
(Figs. 18-3 & 18-4)
Description Part Number
MISCELLANEOUS COMPONENTS
F1 Fuse, SLO-BLO, 10A, 32V, 3AG 10758
J1 Connector, header, single, 3CKT 32802 3
L1 Transformer, hybrid, 50 ohm, XMIT
106630-1 55768
106630-2 55768
L2 Transformer, hybrid, 50 ohm, XMIT
106630-1 55768
106630-2 55769
P1 Connector, JK, male, 64 contact, DIN 98457
R13, 14
Resistor, wirewound, 100Ω, 5%, 10W
100 795
TP3, 4 Test point terminal, orange 98441 3
TP5 Test point, green 38116 5
TP6 Test point, yellow 38116 8
TP7 Test point, red 38116 2
TP8 Test point, white 38116 1
