RFL 9780 RFL Electronics Inc.
April 8, 2003 19-7 (973) 334-3100
Table 19-3. Replaceable parts, RFL 9780 Power Supply module
Assembly No. 106535-1
Circuit Symbol
(Figs. 19-2 & 19-3)
Description Part Number
CAPACITORS
C5 Capacitor, electrolytic, 680µF, 20%, 200V 1007 1813
C6 Capacitor, metalized polyester, 1.0µF, 10%, 250Vdc 1007 1809
C7, 9, 13, 23, 25, Capacitor, ceramic, 1µF, 10%, 50V 1001 6
27, 29, 31, 32,
33, 35, 38, 40,
41, 46, 48
C8, 47 Capacitor, ceramic disc, 470pF, 10%, 1000V 1007 378
C10, 16, 44, Capacitor, ceramic dip, 0.01µF, 10%, 50V 1007 1667
45, 50
C11 Capacitor, ceramic, 0.0047µF, 10%, 50V 1007 1843
C12 Capacitor, ceramic, 0.022µF, 10%, 100V 1007 1840
C14 Capacitor, ceramic, 0.015µF, 10%, 100V 1007 1839
C15 Capacitor, ceramic, 0.047µF, 10%, 100V 1007 1842
C17, 19, 20, 24, Capacitor, electrolytic, 220µF, 20%, 35V 1007 1817
26, 28, 30
C18 Capacitor, ceramic dip, 0.033µF, 10%, 50V 1007 1453
C21, 22, 51, 52, 53, 56 Capacitor, ceramic dip, 0.01µF, 10%, 100V 1007 1390
C34, 36, 37 Capacitor, electrolytic, 2200µF, 20%, 10V 1007 1815
C39 Capacitor, supr x2, 0.01µF, 20%, 250Vac 1007 1810
C49 Capacitor, ceramic, 0.1µF, 10%, 100V 0130 11041
C54, 55 Capacitor, ceramic disc, 470pF, 20%, 3kV 1007 1849
C58 Capacitor, ceramic, 0.0047µF, 5%, 50V 0125 54725
C59 Capacitor, ceramic, 0.1µF, 20%, 50V 1007 1366
RESISTORS
R2 Resistor, metal film, axial, 1K, 1%, 1/2W 0410 2288
R3, 4 Resistor, fixed composition, 10Ω, 5%, 1/4W 1009 823
R5, 6 Resistor, wire wound, 0.10Ω, 1%, 1W 1100 801
R7 Resistor, metal oxide, 10Ω, 5%, 2W 1510 2363
R8 Resistor, metal film, axial, 221K, 1%, 1/4W 0410 1513
R9, 19 Resistor, metal oxide, 100Ω, 5%, 2W 1510 2365
R10 Resistor, metal film, axial, 681Ω, 1%, 1/4W 0410 1272
R11, 13, 14, 16 Resistor, metal film, axial, 10KΩ, 1%, 1/4W 0410 1384
R12 Resistor, metal film, axial, 4.22K, 1%, 1/4W 0410 1348
R15, 37, 39, Resistor, metal film, axial, 1KΩ, 1%, 1/4W 0410 1288
42, 46
R17, 40 Resistor, metal film, axial, 100Ω, 1%, 1/4W 0410 1192
R18 Resistor, metal film, axial, 82.5Ω, 1%, 1/4W 0410 1184
