RFL Electronics 9780 - Table 18-6. Replaceable Parts, RFL 9780 Dual Hybrid Module

RFL 9780 RFL Electronics Inc.
September 8, 2001 18-22 (973) 334-3100
Table 18-6. Replaceable parts, RFL 9780 Dual Hybrid Module
Assembly No. 106620-1-, -2, and -3
Circuit Symbol
(Figs. 18-9 & 18-10)
Description Part Number
MISCELLANEOUS COMPONENTS
CR1 Suppressor, transient, bidirectional, 75V 101473
F1 Fuse, SLO-BLO, 10A, 32V, 3AG 10758
J1-J3 Connector, header, single, 3CKT 32802 3
L1 106620-1: Transformer, hybrid, skewed, 50 ohm, XMIT 55766
106620-2: Transformer, hybrid, skewed, 50 ohm, XMIT 55865
106620-3: Transformer, hybrid, skewed, 50 ohm, XMIT 55865
L2 106620-1: Transformer, hybrid, skewed, 50 ohm, XMIT 55766
106620-2: Transformer, hybrid, skewed, 50 ohm, XMIT 55865
106620-3: Transformer, hybrid, skewed, 75 ohm, REC 55866
L3, 4 Transformer, hybrid, 50 ohm, XMIT 55768
P1 Connector, JK, male, 64 contact, DIN 98457
R1-3
Resistor, fixed composition, 100Ω, 5%, 1W
1009 182
R4
Resistor, metal film, variable, 100Ω, 10%, 2W
44356
R5 Resistor, wirewound, 50Ω, 5%, 2.5W 1100 747
R6 Resistor, wirewound, 50Ω, 5%, 5W 1100 748
R7, 8 Resistor, wirewound, 12Ω, 5%, 2.5W 1100 745
R9-11 Resistor, metal film, precision, 12.1Ω, 1%, 1/2W 1510 2109
R15, 16 Resistor, wirewound, 100Ω, 5%, 10W 1100 795
SW1 Switch, rotary, 1 deck, 6 position 44357
TP1-4 Test point, orange 38441 3
TP5, 9
Test point, green
38116 5
TP6, 10 Test point terminal, yellow 38116 8
TP7 Test point, red 38116 2
TP8 Test point, white 38116 1
