RFL 9780 RFL Electronics Inc.
April 8, 2003 12-8 (973) 334-3100
Table 12-3. Replaceable parts, RFL 9780 IF/BF Module
Assembly No. 106495
Circuit Symbol
(Figs. 12-4 & 12-5)
Description Part Number
CAPACITORS
C1, 18, 27
Capacitor, ceramic 0.1µF, 10%, 50V
0130 51041
C2, 3 Capacitor, ceramic 330pF, 10%, 200V 0130 23311
C4, 5 Capacitor, ceramic, 22pF, 5%, 200V 0125 22205
C6, 7, 24, 37
Capacitor, ceramic, 0.001µF, 5%, 100V
0125 11025
C8-16, 19, 20, 35, 39,
Capacitor, ceramic dip, 0.1µF, 10%, 50V
0120 38
40, 44-60, 62-64, 67,
68, 77-80, 88-92
C17, 36, 69
Capacitor, ceramic, 0.01µF, 10%, 100V
0130 11031
C21 Capacitor, ceramic, 82pF, 5%, 100V 0125 18205
C22 Capacitor, ceramic, 100pF, 5%, 200V 0125 21015
C23 Capacitor, ceramic, 220pF, 10%, 200V 0130 22211
C25, 32
Capacitor, ceramic, 0.1µF, 20%, 50V
1007 1366
C26, 28, 31, 33
Capacitor, ceramic dip, 0.001µF, 10%, 50V
1007 1666
C29 Capacitor, variable ceramic, 5-25pF 30129
C30 Capacitor, ceramic, 33pF, 5%, 200V 0125 23305
C34, 38, 75, 76, 94
Capacitor, tantalum, 1µF, 20%, 35V
1007 496
C41, 42 Capacitor, ceramic, 150pF, 5%, 100V 0125 11515
C43
Capacitor, ceramic, 0.0022µF, 5%, 100V
0125 12225
C61, 65
Capacitor, ceramic 0.47µF, 20%, 50V
0135 54742
C66 Capacitor, ceramic, 5pF +1 – 0.5pF, 200V 0125 25R04
C70 Capacitor, ceramic, 100pF, 5%, 100V 0125 21015
C71 Capacitor, ceramic, 10pF, 10%, 200V 0125 21001
C72
Capacitor, ceramic 0.33µF, +80 -20%, 50V
0135 53348
C73, 74, 81, 82, 93
Capacitor, electrolytic, 47µF, 20%, 35V
1007 1578
C83
Capacitor, tantalum, 2.2µF, 10%, 25V
1007 752
C84
Capacitor, ceramic, 0.0018µF, 5%, 100V
0125 11825
C85
Capacitor, ceramic, 0.0039µF, 5%, 100V
0125 13925
C86, 87
Capacitor, ceramic, 1µF, 10%, 50V
0110 6
RESISTORS
R1, 2, 25, 26 Resistor, metal film, axial, 4.99K, 1%, 1/4W 0410 1355
R3
Resistor, metal film, axial, 51.1Ω, 1%, 1/4W
0410 1164
R4, 27, 31
Resistor, metal film, axial, 110Ω, 1%, 1/4W
0410 1196
R5, 24, 32
Resistor, metal film, axial, 11Ω, 1%, 1/4W
0410 1100
R6 Resistor, metal film, axial, 1.37K, 1%, 1/4W 0410 1301
R7, 30, 33, 40, 43 Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
R8
Resistor, metal film, axial, 887Ω, 1%, 1/4W
0410 1283
R9
Resistor, metal film, axial, 348Ω, 1%, 1/4W
0410 1244
R10 Resistor, variable, ceramic, 1K, 10%, 1/4W 32993
R11
Resistor, metal film, axial, 47.5Ω,, 1%, 1/4W
0410 1161
R12 Resistor, metal film, axial, 53.6K, 1%, 1/4W 0410 1454
R13 Resistor, metal film, axial, 7.15K, 1%, 1/4W 0410 1370
R14 Resistor, metal film, axial, 4.12K, 1%, 1/4W 0410 1347
R15 Resistor, variable, ceramic, 10K, 10%, 1/4W 32996
R16 Resistor, metal film, axial, 221K, 1%, 1/4W 0410 1513
To Next Page
