10.2 SPECIFICATIONS
As of the date this manual was published, the following specifications apply to all RFL 9780 Output
Filter modules, except as indicated. Because all RFL products undergo constant refinement and
improvement, these specifications are subject to change without notice.
Frequency Range:
Assembly No. Frequency Range Notes
106530-1
106530-2
106530-3
106530-4
106530-5
30 kHz to 67.5 kHz.
64 kHz to157.5 kHz.
154 kHz to 393.5 kHz.
390 kHz to 537.5 kHz.
114 kHz to 288.5 kHz.
Without reflected
power measurement
option
106530-11
106530-12
106530-13
106530-14
106530-15
30 kHz to 67.5 kHz.
64 kHz to157.5 kHz.
154 kHz to 393.5 kHz.
390 kHz to 537.5 kHz.
114 kHz to 288.5 kHz.
With reflected power
measurement option
Attenuation Notch:
Magnitude: Greater than 55 dB below passband level.
Approximate Frequency: See Table 10-2
Stopband:
Attenuation: Greater than 45 dB below passband level.
Approximate Frequency Range:
106530-1, -11: 90 kHz to 2 MHz.
106530-2, -12: 192 kHz to 2 MHz.
106530-3, -13: 462 kHz to 2 MHz.
106530-4, -14: 1.17 MHz to 2 MHz.
106530-5, -15: 342 kHz to 2mHz.
Passband: 0.75 dB deviation.
Signal Power: 10 watts maximum.
Impedance: 50 ohms.
