Table 17-13. Replaceable Parts, RFL 9780 Alarm Relay I/O module
Assembly No. 106465
Circuit Symbol
(Figs. 17-20 & 17-21)
Description Part Number
C1-12
Capacitor, ceramic disc, 0.01µF, 20%, 3KV
1007 1811
CR1-4 Diode, silicon, rectifier, 1A, 1N4003 30769
J1, 2 Connector, wafer assy, 5 circuit 97223 5
K1-4 Relay, DPDT, 12V, PCB mount 101718
L1-12
Inductor, 10µH, 5%, 1.5A max
30285
P1 Connector, plug. Female, 64 contact, DIN 99134
TB1, 2 Terminal block, 6 position 101462
