6.3 TYPICAL CONFIGURATION SETTINGS
The Tables below list some typical configuration settings for the 9780 FSK PLC. Note that these
settings are typical, and are not standard settings. Each RFL 9780 application is unique and should be
carefully evaluated by a knowledgeable Engineer. Normally, when a unit is shipped from RFL it is
shipped configured for the user's application. If, however, RFL is not aware of application specifics,
the system will be supplied with the typical settings. RFL Sales and Customer Support personnel are
always available to answer questions or assist in configuring a system.
Table 6-1. 9780 DTT Application
Function Typical Setting Switch Positions
Bi-Polar Noise 12 msec SW1-1 SW1-2 SW1-3
Detector ON ON OFF
Pre-Guard Timer 4 msec SW1-4 SW1-5 SW1-6 SW1-7 SW1-8
OFF OFF ON OFF OFF
Unblock Trip Rectore N/A SW2-1
OFF
Pre-Trip Timer
5.25 msec in a ±100 Hz shift system,
SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8
Providing a 12 msec TCT. OFF OFF ON OFF ON OFF ON
Unblock Trip Window N/A SW3-1 SW3-2 SW3-3
OFF OFF OFF
Guard Hold Timer 10 msec, to avoid nuisance guard dropouts SW3-4 SW3-5 SW3-6 SW3-7 SW3-8
(a valid trip will always override the guard). OFF ON OFF ON OFF
Unblock Security Disabled SW4-1 SW4-2 SW4-3
Timer OFF OFF OFF
Trip Hold Timer 0 msec SW4-4 SW4-5 SW4-6 SW4-7 SW4-8
OFF OFF OFF OFF OFF
Trip After Guard 100 msec SW5-1 SW5-2 SW5-3 SW5-4
OFF ON ON OFF
Guard Before Trip 100 msec SW5-5 SW5-6 SW5-7 SW5-8
OFF ON ON OFF
Alarm Pick-Up 300 msec SW6-1 SW6-2 SW6-3 SW6-4
OFF OFF ON ON
Alarm Drop-Out 50 msec SW6-5 SW6-6 SW6-7 SW6-8
OFF OFF OFF OFF
Trip Latch Disabled SW7-1
OFF
Power Boost Level 1W/10W SW7-2 SW7-3 SW7-4 SW7-5
OFF OFF ON OFF
Not Used N/A SW7-6
OFF
Keying Mode 2F, Dual-Trip Keying SW7-7 SW7-8
OFF ON
Carrier Envelope Enabled SW8-1
Noise Detect ON
TX Trip Shift TX Guard=Shift Up, TX Trip=Shift Down SW8-2
Direction OFF
Trip 1 Polarity De-energized SW8-3
OFF
Trip 2 Polarity De-energized SW8-4
OFF
RX Trip Shift RX Guard=Shift Up, RX Trip=Shift Down SW8-5
Direction OFF
Not Used N/A SW8-6 SW8-7 SW8-8
OFF OFF OFF
