RFL Electronics 9780 - Table 20-4. Replaceable Parts, RFL 9780 Rx;Rx Motherboard

RFL 9780 RFL Electronics Inc.
April 8, 2003 20-6 (973) 334-3100
Table 20-4. Replaceable parts, RFL 9780 Rx/Rx Motherboard
Assembly No. 106555-2
Circuit Symbol
(Figs. 20-4 & 20-10)
Description Part Number
C1-3, 10-16
C4, 5
C6-9
J1, 3, 5, 8, 9, 11
J2, 4, 7
J6, 10
J12, 15-23, 25-27
Capacitor, ceramic disc, 0.1µF, 10%, 100V
Capacitor, electrolytic, 1000µF, 20%, 10V
Capacitor, electrolytic, 470µF, 20%, 25V
Connector, JK, female, 64 contact, DIN
Connector, JK, female, 64 contact, DIN
Connector, wafer assembly, 2 circuit
Connector jack, receptacle, SMB
0130 11041
1007 1746
1007 1856
101280 1
101281 1
101679 1
101485
