RFL Electronics 9780 - Table 9-2. Replacement Parts, RFL 9780 Power Amplifier Module Assembly No. 106460

RFL 9780 RFL Electronics Inc.
May 19, 2000 9-5 (973) 334-3100
Table 9-2. Replacement parts, RFL 9780 Power Amplifier Module
Assembly No. 106460
Circuit Symbol
(Figs. 9-3 & 9-4)
Description Part Number
CAPACITORS
C1, 15
Capacitor, ceramic, 1µF, 20%, 50V
0135 51052
C2, 4, 11, 12
Capacitor, ceramic, 0.1µF, 10%, 50V
0130 51041
C3, 5
Capacitor, electrolytic, 220µF, 20%, 35V
1007 1814
C6 Capacitor, ceramic dip, 10pF, 10%, 200V 1007 1462
C7, 8
Capacitor, MPC, 3µF, 5%, 50V
1007 1287
C9
Capacitor, ceramic dip, 0.01µF, 10%, 100V
1007 1390
C10
Capacitor, ceramic, 0.1µF, 20%, 50V
1007 1366
C13
Capacitor, tantalum, 3.3µF, 20%, 35V
1007 1260
C14
Capacitor, tantalum, 3.3µF, 10%, 50V
1007 1466
RESISTORS
R1, 4, 7-9, 13, 14 Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
R2 Resistor, ceramic, variable, 1K, 10%, 1/4W 32993
R3
Resistor, metal film, axial, 374Ω, 1%, 1/4W
0410 1247
R5, 6, 15
Resistor, wire wound, NI, 0.25Ω, 5%, 3W
1100 743
R10 Resistor, ceramic, variable, 100K, 10%, 1/4W 32999
R11 Resistor, metal film, axial, 47.5K, 1%, 1/4W 0410 1449
R12
Resistor, metal film, axial, 715Ω, 1%, 1/4W
0410 1274
R17
Resistor, metal film, axial, 75Ω, 1%, 1/4W
0410 1180
SEMICONDUCTORS
CR3, 5 Suppressor, transient voltage, 1.5KE30CA 100556
CR4, 6 Diode, fast recovery, 1A, 400V 103484
CR7 Diode, silicon, 1N914B/1N4448 26482
U2 Integrated circuit, linear voltage comparator, buffer 0620 188
MISCELLANEOUS COMPONENTS
P1 Connector, plug, female, 64 contact, DIN 99134
T1 Transformer assembly, output 102726
