17.8.2 PROGRAMMABLE JUMPERS
Figures 17-28 through 17-35, and Figures 17-37, 17-39 and 17-41 show the location of all
programmable jumpers in addition to component locations on the Line I/O modules. How to set these
jumpers is described in Table 17-16. Only terminal blocks and RF connectors are accessible with the
Line I/O modules installed in the chassis. All jumpers are accessible only when the modules are
removed from the chassis or are on card extenders.
Table 17 16. Setting Programmable Jumpers On Line I/O Modules
I/O Module Jumper
Designator
Function
106585-3 J3
Selects line termination impedance of 50Ω, 75Ω, or OUT (Greater than 30KΩ)
106585-4 J3
Selects line termination impedance of 50Ω, 75Ω, or OUT (Greater than 30KΩ)
106585-5 J3
Selects line termination impedance of 50Ω, 75Ω, or OUT (Greater than 30KΩ)
106585-7 J3
Selects line termination impedance of 50Ω, 75Ω, or OUT (Greater than 30KΩ)
106585-8 J3
Selects line termination impedance of 50Ω, 75Ω, or OUT (Greater than 30KΩ)
106585-9 J3
Selects line termination impedance of 50Ω, 75Ω, or OUT (Greater than 30KΩ)
106605 J3
Selects line termination impedance of 50Ω, 75Ω, or OUT (Greater than 30KΩ)
Table 17-17. Replaceable parts, Line I/O modules 106585-1 thru 106585-9 (See Note 1)
Circuit Symbol
(Figs. 17-22 thru 17-29, and 17-
31)
Description Part Number
R1, 2, 3
Resistor, fixed composition, 100Ω, 5%, 1W
1009 182
R4, 5
Resistor, fixed composition, 150Ω, 5%, 1W
1009 183
E1, E2, E3 Arrestor, 2-element gas tube 101472
CR1 Suppressor, transient, bi-directional, 75V 101473
J10, 12, 14, 15, 16, 18, Connector, jack, female, 2-contact, SMB 101485
20, 22, 23
J3 Connector, header, dual 3/6 circuit 32599 6
J5, 6, 7, 8 Connector, jack, coax, female 101470
J1, 2 Connector wafer assembly, 4 circuit 97223 4
TB1, 2 Terminal block, 8-terminal, modified 101697 8
TB1 Terminal block, 2-terminal, modified 101697 2
Note 1:Refer to the Table in Figure 17-36 (schematic diagram) to determine which components are
used in which Line I/O modules. The schematic shown in Figure 17-36 is for Line I/O modules
106585-1 to 106585-8. The schematic shown in Figure 17-38 is for Line I/O module 106585-9.
