RFL 9780 RFL Electronics Inc.
April 8, 2003 15-6 (973) 334-3100
Table 15-3. Replaceable parts, RFL 9780 SOE/IRIG-B Module, Assembly No. 106480-1
Circuit Symbol
(Figs. 15-3 & 15-4)
Description Part
Number
CAPACITORS
C1, 2, 3, 10
Capacitor, electrolytic, 47µF, 20%, 35V
1007 1578
C4-6, 11-15, 17-25, 28, 42,
Capacitor, ceramic dip, 0.1µF, 10%, 50V
0120 38
57-59, 72-75, 78-80, 82, 84
C7 Capacitor, ceramic, 220pF, 5%, 100V 0125 12215
C8, 9 Capacitor, ceramic, 33pF, 10%, 200V 0125 23301
C16
Capacitor, ceramic, 0.0039µF, 5%, 100V
0125 13925
C29-33, 37-41
Capacitor, tantalum, 1µF, 10%, 35V
1007 1768
C36
Capacitor, ceramic, 0.27µF, 10%, 50V
1007 1682
C43-47
Capacitor, ceramic, 0.001µF, 10%, 100V
0130 11021
C48-52
Capacitor, ceramic disc, 0.002µF, 20%, 1000V
1007 942
C53-56
Capacitor, ceramic, 0.01µF, 10%, 50V
0130 51031
C76
Capacitor, tantalum, .033µF, 10%, 35V
1007 1281
RESISTORS
R1, 24, 37-44 Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
R2, 5
Resistor, metal film, axial, 909Ω, 1%, 1/2W
0410 2284
R3, 4, 14 Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
R6, 27-30 Resistor, metal film, axial, 20K, 1%, 1/4W 0410 1413
R7, 12, 33-36, 45, 46 Resistor, metal film, axial, 4.99K, 1%, 1/4W 0410 1355
R8 Resistor, metal film, axial, 4.02K, 1%, 1/4W 0410 1346
R9
Resistor, metal film, axial, 432Ω, 1%, 1/5W
0410 2253
R10 Resistor, metal film, axial, 2.0M, 1%, 1/4W 0410 1605
R11 Resistor, metal film, axial, 8.25K, 1%, 1/4W 0410 1376
R13, 18, 31, 32 Resistor, metal film, axial, 237K, 1%, 1/4W 0410 1516
R15, 16 Resistor, metal film, axial, 24.9K, 1%, 1/4W 0410 1422
R17 Resistor, metal film, axial, 2K, 1%, 1/4W 0410 1317
R19-23
Resistor, metal film, axial, 221Ω, 1%, 1/4W
0410 1225
R25, 26 Resistor, metal film, axial, 316K, 1%, 1/4W 0410 1336
RZ1 Resistor, network, 10K, 8R/PKG, SIP 95571
RZ2 Resistor, network, 22K, 7R/PKG, SIP 101484
RZ3 Resistor, network, 47K, 7R/PKG, SIP 47880
SEMICONDUCTORS
U1, 15 Integrated circuit, interface, 5V, RS-232, dual 0680 12
U2 Integrated circuit, peripheral, microprocessor, supervisor 0635 31
U3 Integrated circuit, microprocessor, 8-bit 0640 36
U4 Integrated circuit, EPROM, 64Kx8 0615 452
U5 Integrated circuit, MOS, non-volatile SRAM, RTC, 8Kx8 0615 474
U6 Integrated circuit, MOS, CPLD 0615 472
