Table 15-3. continued - Replaceable parts, RFL 9780 SOE/IRIG-B Module
Circuit Symbol
(Figs. 15-3 & 15-4)
Description Part Number
SEMICONDUCTORS continued
U7 Integrated circuit, linear, quad, comparator 0620 241
U8 Integrated circuit, analog switch, quad, SPST, CMOS 0605 17
U9 Integrated circuit, MOS, timer 0615 328
U10 Integrated circuit, linear adj precision shunt regulator 0620 320
U11, Integrated circuit, MOS, CPLD 0615 490
U12 Integrated circuit, A/D converter, high speed 0625 41
U16 Integrated circuit, linear voltage regulator, neg 5V 0620 210
CR1, 2, 3 Diode, silicon, 1N914B/1N4448 26482
CR4, 5, 6 Suppressor, transient voltage, P6KE30CA 100576
CR7, 8 Suppressor, transient voltage, P6KE16CA 100572
CR9, 10, 11, 12 Diode, Schottky barrier, 1N6263 93631
CRZ1 Diode array, 8-diode, common cathode 103444
Q1 Transistor, silicon, NPN, 2N2222A 37445
MISCELLANEOUS COMPONENTS
J1, 3, 5 Connector, header, single, 3-circuit 32802 3
J4, 6 Connector, header, single, 7-circuit 32802 7
J8 Connector, wafer assembly, RT angle, 6 ckt 98202 6
J9 Connector, wafer assembly, 7 ckt 97223 7
P1 Connector, JK male, 64 contact, DIN 98457
SW1 Switch, DIP, SPST, 8-position, 16-pin 98493
TP1, 2, 3 Test point, terminal, orange 98441 3
Y1 Crystal, HC-18, 12MHz 30555
