RFL Electronics 9780 - Table 11-3. Replaceable Parts, RFL 9780 RF Interface Module Assembly No. 106500

RFL 9780 RFL Electronics Inc.
May 19, 2000 11-17 (973) 334-3100
Table 11-3. Replaceable parts, RFL 9780 RF Interface Module
Assembly No. 106500
Circuit Symbol
(Figs. 11-4 & 11-5)
Description Part
Number
CAPACITORS
C1, 2
Capacitor, electrolytic, 47µF, 20%, 35V
1007 1578
C3-6, 8, 20-37
Capacitor, ceramic dip, 0.1µF, 10%, 50V
0120 38
C7 Capacitor, ceramic, 47pF, 5%, 200V 0125 24705
C9, 11, 12, 14 Capacitor, ceramic, 390pF, 1%, 100V 1007 1851
C10
Capacitor, ceramic, 1µF, 10%, 50V
0110 6
C13
Capacitor, tantalum, 10µF, 10%, 20V
1007 955
C15
Capacitor, ceramic, 0.47µF, 20%, 50V
0135 54742
RESISTORS
R1, 8 Resistor, metal film ,axial, 4.99K, 1%, 1/4W 0410 1355
R2 Resistor, metal film ,axial, 21K, 1%, 1/4W 0410 1415
R3 Resistor, metal film ,axial, 7.15K, 1%, 1/4W 0410 1370
R4 Resistor, metal film ,axial, 2.15K, 1%, 1/4W 0410 1320
R5
Resistor, metal film ,axial, 681 Ω, 1%, 1/4W
0410 1272
R6
Resistor, metal film ,axial, 215 Ω, 1%, 1/4W
0410 1224
R7, 12, 57
Resistor, metal film ,axial, 100 Ω, 1%, 1/4W
0410 1192
R9, 11 Resistor, metal film ,axial, 1K, 1%, 1/4W 0410 1288
R10
Resistor, metal film ,axial, 332 Ω, 1%, 1/4W
0410 1242
R13 Resistor, metal film ,variable, 5K, 10%, 3/4W 39538
R14, 44 Resistor, metal film ,axial, 23.7K, 1%, 1/4W 0410 1420
R15, 45 Resistor, metal film ,axial, 41.2K, 1%, 1/4W 0410 1443
R16, 46
Resistor, metal film ,variable, 20 Ω, 20%, 1/2W
105412
R17
Resistor, metal film ,precision, 27.4 Ω, 1%, 1/8W
1510 1425
R18, 47 Resistor, metal film ,axial, 1.24K, 1%, 1/4W 0410 1297
R19, 48 Resistor, metal film ,axial, 1.13K, 1%, 1/4W 0410 1293
R20, 49
Resistor, metal film ,variable, 100 Ω, 10%, 1/2W
96706
R21, 23 Resistor, metal film ,axial, 11K, 1%, 1/4W 0410 1388
R22, 51
Resistor, metal film ,axial, 11 Ω, 1%, 1/4W
0410 1100
R24, 34, 61, 71 Resistor, metal film ,axial, 1.54K, 1%, 1/4W 0410 1306
R25, 35, 62, 72 Resistor, metal film ,axial, 3.09K, 1%, 1/4W 0410 1335
R26, 36, 63, 73 Resistor, metal film ,axial, 6.19K, 1%, 1/4W 0410 1364
R27, 37, 64, 74 Resistor, metal film ,axial, 12.4K, 1%, 1/4W 0410 1393
R28, 38, 65, 75 Resistor, metal film ,axial, 24.9K, 1%, 1/4W 0410 1422
R29, 39, 66, 76 Resistor, metal film ,axial, 49.9K, 1%, 1/4W 0410 1451
R30, 40, 67, 77 Resistor, metal film ,axial, 100K, 1%, 1/4W 0410 1480
R31, 41, 68, 78 Resistor, metal film ,axial, 200K, 1%, 1/4W 0410 1509
R32, 42, 69, 79 Resistor, metal film ,axial, 402K, 1%, 1/4W 0410 1538
R33, 43, 70, 80 Resistor, metal film ,axial, 806K, 1%, 1/4W 0410 1567
R50 Resistor, metal film ,axial, 16.5K, 1%, 1/4W 0410 1405
R52 Resistor, metal film ,axial, 16.2K, 1%, 1/4W 0410 1404
R53, 54 Resistor, metal film ,axial, 40.2K, 1%, 1/4W 0410 1442
R55
Resistor, metal film ,axial, 499 Ω, 1%, 1/4W
0410 1259
