Table 11-3. – continued. Replaceable parts, RFL 9780 RF Interface Module
Assembly No. 106500
Circuit Symbol
(Figs. 11-4 & 11-5)
Description Part
Number
RESISTORS - continued
R56 Resistor, metal film ,axial, 10K, 1%, 1/4W 0410 1384
R58 Resistor, metal film ,axial, 6.49K, 1%, 1/4W 0410 1366
R59 Resistor, metal film ,axial, 7.5K, 1%, 1/4W 0410 1372
R60 Resistor, metal film ,axial, 2K, 1%, 1/4W 0410 1317
R81, 82
Resistor, fixed composition, 2.2 Ω, 5%, 1/2W
1009 1059
SEMICONDUCTORS
CR1, 2, 7, 8 Diode, Zener, 6.8V, 5%, 1W, 1N4736A 29752
CR3 Diode, surmetic, rectifier, 1N4001 38876
CR4 Diode, Zener, 8.2V, 5%, 1W, 1N4738A 29754
CR5, 6 Diode, silicon, 1N914B/1N4448 26482
Q1, 2, 3 Transistor, silicon, PNP, 2N3906 21565
U1-8 IC, linear, OPAMP, EL2044CN 0620 384
U9 IC, analog switch, QUAD, SPST, CMOS 0605 17
MISCELLANEOUS COMPONENTS
J1, 3 Connector, header, single, 3 CKT 32802 3
J2 Connector, header, dual, 6/12 CKT 32599 12
L1, 2
Inductor, molded, 56µH, 100ma
32824
P1 Connector, JK male, 64 cont, DIN 98457
SW1-4 DIP switch, 10 position, SPST 101474
TP1-7, 11-12 Test point terminal orange 98441 3
TP8 Test point, black, PC mount 38116 3
TP9 Test point, red, PC mount 38116 2
TP10 Test point, brown, PC mount 38116 4
