RFL 9780 RFL Electronics Inc.
April 8, 2003 17-8 (973) 334-3100
Table 17-3. Replaceable Parts, RFL 9780 Solid State Relay I/O module
Assy No. 106435-3 & -4
Circuit Symbol
(Figs. 17-4 & 17-5)
Description Part Number
C7,8
Capacitor, ceramic, 0.1µF, 10%, 50V
0130 51041
C9-15
Capacitor, ceramic disc, 0.01µF, 20%, 3KV
1007 1811
C16
Capacitor, electrolytic, 100µF, 20%, 25V
1007 1630
CR9, 10 101635-3: Diode, Zener, 20V, 5%, 1W, 1N4747A 20794
101635-4: Diode, Zener, 75V, 5%, 1W, 1N4761A 101693
CR11, 12, 14 Diode, silicon, rectifier, 1A, 1N4003 30769
J4, 5 Connector, header, single, 3 CKT 32802 3
K1 Relay, SPST, 8A/300V, 6V/0.22W 101461
L5, 6, 7, 8
Inductor, 10µH, 5%, 1.5A max
30285
P1 Connector, plug, female, 64 contact, DIN 99134
R7, 8 Resistor, metal film, axial, 4.75K, 1%, 1/4W 0410 1353
R9, 10
Resistor, metal film, axial, 221Ω, 1%, 1/4W
0410 1225
R11, 12 106435-3: Resistor, wire-wound, 22K, 5%, 5W 1100 800
106435-4: Resistor, wire-wound, 20K, 5%, 5W 1100 837
R13, 14 106435-3: Resistor, metal film, axial, 11.5K, 1%, 1/4W 0410 1390
106435-4: Resistor, metal film, axial, 47.5K, 1%, 1/4W 0410 1449
R15, 16 106435-3: Resistor, wire-wound, 5K, 5%, 3.25W 1100 460
106435-4: Resistor, wire-wound, 25K, 5%, 5W 1100 480
R17
Resistor, metal film, axial, 162Ω, 1%, 1/2W
0410 2212
R20
106435-3: Resistor, metal film, axial, 11Ω, 1%, 1/4W
0410 1100
106435-4: not used
TB1 Terminal block, 7 position 101463
U1, 2 Opto device, optical isolator, 6N139 29592
J4, 5 Jumper, connector, programmable, 0.1 inch centers, white 98306
