RFL 9780 RFL Electronics Inc.
November 1, 2000 7-12 (973) 334-3100
Table 7-9. Replaceable parts, RFL 9780 Tx Logic Module Assemble No. 106490-1
Circuit Symbol
(Figs. 7-4 & 7-5)
Description Part Number
CAPACITORS
C1, 2
Capacitor, electrolytic, 47µF, 20%, 35V
1007 1578
C5, 6, 17, 20, 22-24,
Capacitor, ceramic dip, 0.1µF, 10%, 50V
0120 38
26-32, 34-36
C15, 16
Capacitor, ceramic, 0.0056µF, 5%, 100V
0125 15625
C19
Capacitor, tantalum, 4.7µF, 10%, 35V
1007 1623
C21
Capacitor, ceramic dip, 0.01µF, 5%, 100V
1007 1645
RESISTORS
R1 Resistor, metal film, axial, 6.49K, 1%, 1/4W 0410 1366
R2 Resistor, metal film, axial, 2.05K, 1%, 1/4W 0410 1318
R21, 22, 31, 36, 37, Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
40, 42, 45
R4 Resistor, metal film, axial, 127K, 1%, 1/4W 0410 1490
R29, 44 Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
R24, 25 Resistor, metal film, axial, 33.2K, 1%, 1/4W 0410 1434
R26, 27 Resistor, metal film, axial, 3.92K, 1%, 1/4W 0410 1345
R30 Resistor, metal film, axial, 49.9K, 1%, 1/4W 0410 1451
R43 Resistor, metal film, axial, 4.75K, 1%, 1/4W 0410 1353
RZ1 Resistor network, 4.7K, 8R/PKG, SIP 101676
RZ2 Resistor network, 10K, 8R/PKG, SIP 95571
RZ3
Resistor network, 330Ω, 8R/PKG, SIP
44532
RZ4 Resistor network, 22K, 8R/PKG, SIP 32876
SEMICONDUCTORS
CR7 Diode, silicon, 1N914B/1N4448 26482
CRZ1, 2 Diode array, 8-diode, common cathode 103444
U3, 5, 6, 9 Integrated circuit, MOS 0615 297
U4 Integrated circuit, MOS HEX inverter, Schmitt trigger 0615 242
U7 Transistor array, ULN2803A 0720 7
U12 Integrated circuit, MOS, quad, buffer, line driver 0615 292
U13 Integrated circuit, MOS, three to eight line decoder 0615 168
U15 Integrated circuit, MOS, octal, 3-state, DFF 0615 298
MISCELLANEOUS COMPONENTS
DS1-3 Opto device, LED, red 98534
L1
Inductor, coated, 100µH, 10%
103472
P1 Connector, plug, male, 96 connections, DIN 101681
SW1, 2 Switch, DIP, SPST, 8-position, 16-pin 98493
SW11 Switch, SPDT, right angle, pc board mounting 98488
TP1, 3, 6, 7, 14, 15, Test point, terminal, orange 98441 3
16, 21, 22
Y1 Crystal, hybrid, clock oscillator, 3.584Mhz 103347
