RFL Electronics 9780 - Table 8-2. Replaceable Parts, RFL 9780 Transmitter Module Assembly No. 106505

RFL 9780 RFL Electronics Inc.
November 1, 2000 8-8 (973) 334-3100
Table 8-2. Replaceable parts, RFL 9780 Transmitter Module
Assembly No. 106505
Circuit Symbol
(Figs. 8-3 & 8-4)
Description Part Number
CAPACITORS
C1, 2, 3
Capacitor, electrolytic, 47µF, 20%, 35V
1007 1578
C4-8, 10, 11, 14, 17,
Capacitor, ceramic dip, 0.1µF, 10%, 50V
0120 38
21-26, 28
C9, 12
Capacitor, ceramic dip, 0.01µF, 5%, 100V
1007 1645
C15, 16
Capacitor, tantalum, 3.3µF, 20%, 35V
1007 1260
C18 Capacitor, ceramic, 470pF, 5%, 100V 0125 14715
C19
Capacitor, ceramic, 0.0015µF, 5%, 100V
0125 11525
C20 Capacitor, ceramic, 33pF, 5%, 200V 0125 23305
C27
Capacitor, tantalum, 1µF, 10%, 35V
1007 1156
RESISTORS
R1, 9, 10 Resistor, metal film, axial, 49.9K, 1%, 1/4W 0410 1451
R2, 11-14, 20 Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
R3, 4
Resistor, metal film, axial, 51.1Ω, 1%, 1/4W
0410 1164
R5 Resistor, metal film, axial, 32.4K, 1%, 1/4W 0410 1433
R6 Resistor, metal film, axial, 107K, 1%, 1/4W 0410 1483
R7 Resistor, metal film, axial, 3.74K, 1%, 1/4W 0410 1343
R8 Resistor, metal film, axial, 2K, 1%, 1/4W 0410 1317
R15, 16, 17
Resistor, metal film, axial, 787Ω, 1%, 1/4W
0410 1278
R18, 23 Resistor, metal film, variable, 10K, 10%, 1/2W 48548
R19, 25, 26 Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
R21 Resistor, metal film, axial, 4.64K, 1%, 1/4W 0410 1352
R22 Resistor, metal film, axial, 22.6K, 1%, 1/4W 0410 1418
R24 Resistor, metal film, axial, 45.3K, 1%, 1/4W 0410 1447
R27 Resistor, metal film, axial, 12.1K, 1%, 1/4W 0410 1392
R28 Resistor, metal film, axial, 7.5K, 1%, 1/4W 0410 1372
R29 Resistor, metal film, axial, 4.99K, 1%, 1/4W 0410 1355
R30 Resistor, metal film, axial, 68.1K, 1%, 1/4W 0410 1464
R31 Resistor, metal film, axial, 1M, 1%, 1/4W 0410 1576
RZ1 Resistor, network, 1K, 8R/PKG SIP 95570
RZ2 Resistor, network, 10K, 8R/PKG SIP 95571
