RFL Electronics 9780 - Table 13-3. Replaceable Parts, RFL 9780 Carrier Level Indicator Module

RFL 9780 RFL Electronics Inc.
April 8, 2003 13-11 (973) 334-3100
Table 13-3. Replaceable parts, RFL 9780 Carrier Level Indicator Module
Assembly No. 106485-5
Circuit Symbol
(Fig. 13-4 & 13-5)
Description Part Number
CAPACITORS
C1, 2, 41
Capacitor, electrolytic, 47µF, 20%, 35V
1007 1578
C3, 6, 7, 10, 12
Capacitor, ceramic, 0.0068µF, 5%, 100V
0125 16825
C4, 5, 8, 13, 24-26, 29, 33, 35,
Capacitor, ceramic dip, 0.1µF, 10%, 50V
0120 38
39, 40, 43, 44, 48-50, 52, 53
C14, 16
Capacitor, ceramic, 0.0033µF, 5%, 100V
0125 13325
C15, 22
Capacitor, ceramic, 0.0056µF, 5%, 100V
0125 12225
C23
Capacitor, ceramic, 1µF, 10%, 50V
0110 6
C27 Capacitor, ceramic, 330pF, 10%, 200V 0130 23311
C28 Capacitor, ceramic, 150pF, 5%, 100V 0125 11515
C30, 42, 45-47
Capacitor, ceramic dip, 0.01µF, 5%, 100V
1007 1645
C31, 32
Capacitor, ceramic, 0.47µF, +80 -20%, 50V
1007 939
C34
Capacitor, tantalum, 15µF, 20%, 35V
1007 539
C36
Capacitor, ceramic, 0.047µF, 10%, 50V
0130 54731
C51 Capacitor, ceramic, 680pF, 5%, 100V 0125 16815
RESISTORS
R1, 2
Resistor, fixed composition, 2.7Ω, 5%, 1/4W
1009 900
R3, 28, 29, 35, 54, 66,
Resistor, metal film, axial, 100Ω, 1%, 1/4W
0410 1192
67, 69, 90, 91, 96
R4 Resistor, zero ohm 0510 2217
R5 Resistor, metal film, axial, 47.5K, 1%, 1/4W 0410 1449
R6, 8, 9 Resistor, metal film, axial, 4.22K, 1%, 1/4W 0410 1348
R7 Resistor, metal film, axial, 2.1K, 1%, 1/4W 0410 1319
R10 Resistor, metal film, axial, 3.83K, 1%, 1/4W 0410 1344
R11, 17, 106 Resistor, metal film, variable, 1K, 10%, 1/2W 49995
R12, 26, 27 Resistor, metal film, axial, 1.96K, 1%, 1/4W 0410 1316
R13, 19, 20 Resistor, metal film, axial, 13K, 1%, 1/4W 0410 1395
R14, 89 Resistor, metal film, axial, 3.01K, 1%, 1/4W 0410 1334
R15, 18 Resistor, metal film, axial, 6.49K, 1%, 1/4W 0410 1366
R16 Resistor, metal film, axial, 6.04K, 1%, 1/4W 0410 1363
R21 Resistor, metal film, axial, 12.4K, 1%, 1/4W 0410 1393
R22, 24, 25 Resistor, metal film, axial, 20K, 1%, 1/4W 0410 1413
R23 Resistor, metal film, variable, 5K, 10%, 1/2W 94271
R30 Resistor, metal film, variable, 10K, 10%, 3/4W 39539
R32, 43, 45-48, 50, 52, 56 Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
64, 79
R33, 85 Resistor, metal film, axial, 26.7K, 1%, 1/4W 0410 1425
R36 Resistor, metal film, axial, 82.5K, 1%, 1/4W 0410 1472
R37
Thermistor, resistor, 1000Ω, 1%
91529
R38 Resistor, metal film, axial, 2.21K, 1%, 1/4W 0410 1321
