RFL Electronics 9780 - Table 20-2. Replaceable Parts, RFL 9780 Tx;Rx Motherboard

RFL 9780 RFL Electronics Inc.
April 8, 2003 20-2 (973) 334-3100
Table 20-2. Replaceable parts, RFL 9780 Tx/Rx Motherboard
Assembly No. 106450-2
Circuit Symbol
(Figs. 20-2 & 20-8)
Description Part Number
C1, 2, 3, 14-20
C4, 5
C7, 8, 10-12
J1, 3, 8-11
J2, 4, 5, 7
J6
J16
J17-22, 24, 26
J23
Capacitor, ceramic, 0.1µF, 10%, 100V
Capacitor, electrolytic, 1000µF, 20%, 10V
Capacitor, electrolytic, 470µF, 20%, 25V
Connector, JK, female, 64 contact, DIN
Connector, JK, female, 64 contact, DIN
Connector, JK, female, 96 contact, DIN
Connector, wafer assembly, 2 circuit
Connector, jack receptacle, SMB
Connector, header, dual, 3/6 circuit
0130 11041
1007 1746
1007 1856
101280 1
101281 1
101679 1
97223 2
101485
32599 6
