RFL Electronics 9780 - Table 17-8. Replaceable Parts, RFL 9780 Solid-State Input;Output I;O Module

RFL 9780 RFL Electronics Inc.
April 8, 2003 17-28 (973) 334-3100
Table 17-8. Replaceable Parts, RFL 9780 Solid-State Input/Output I/O module
Assy No. 106445-3 & -4
Circuit Symbol
(Figs. 17-12 & 17-13)
Description Part Number
Input Board Components
C7,8
Capacitor, ceramic, 0.1µF, 10%, 50V
0130 51041
C9-15
Capacitor, ceramic disc, 0.01µF, 20%, 3KV
1007 1811
C16
Capacitor, electrolytic, 100µF, 20%, 25V
1007 1630
CR9, 10 106445-3; Diode, Zener, 20V, 5%, 1W, 1N4747A 20794
106445-4; Diode, Zener, 75V, 5%, 1W, 1N4761A 101693
CR11, 12, 14 Diode, silicon, rectifier, 1A, 1N4003 30769
J8 Connector, wafer assembly, 6-CKT 97223 6
K1 Relay, SPST, 8A/300V, 6V/0.22W 101461
L5, 6, 7, 8
Inductor, 10µH, 5%, 1.5A max
30285
P1 Connector, plug, female, 64 contact, DIN 99134
R7, 8 Resistor, metal film, axial, 4.75K, 1%, 1/4W 0410 1353
R9, 10
Resistor, metal film, axial, 221Ω, 1%, 1/4W
0410 1225
R11, 12 106445-3: Resistor, wire-wound, 22K, 5%, 5W 1100 800
106445-4: Resistor, wire-wound, 20K, 5%, 5W 1100 837
R13, 14 106445-3: Resistor, metal film, axial, 11.5K, 1%, 1/4W 0410 1390
106445-4: Resistor, metal film, axial, 47.5K, 1%, 1/4W 0410 1449
R15, 16 106445-3: Resistor, wire-wound, 5K, 5%, 3.25W 1100 460
106445-4: Resistor, wire-wound, 25K, 5%, 5W 1100 480
R17
Resistor, metal film, axial, 162Ω, 1%, 1/2W
0410 2212
R20 Resistor, metal film, axial, 11, 1%, 1/4W 0410 1100
TB1 Terminal block, 7 position 101463
U1, 2 Opto device, optical isolator, 6N139 29592
Output Board Components
C101, 102 Capacitor, ceramic, 4700pF, 5%, 50V 151 05472040507
C103-106
Capacitor, ceramic disc, 0.01µF, 20%, 3KV
1007 1811
C111, 114, 132,
Capacitor, ceramic, 0.1µF, 10%, 50V
151 10104040603
135-137, 139
C112, 113, 130, 131
Capacitor, ceramic, 0.47µF, 10%, 16V
151 10474020603
C133, 134
Capacitor, ceramic, 0.01µF, 10%, 50V
151 10103040603
CR101, 102, 105, 106 Diode, general purpose, 1N4148 340 100
CR103, 104 106445-3: Suppressor, transient voltage, 1.5KE180CA 42064
106445-4: Suppressor, transient voltage, 1.5KE350CA 101722
J108 Connector, wafer assembly, 6-CKT 97223 6
L101-104
Inductor, 12µH, 4.5A, 10%
30436
Q101, 102 106445-3: Transistor, MOSFET, N-channel 0715 36
106445-4: Transistor, MOSFET, N-channel 0715 37
R101, 102, 105, 106
Resistor, thick film, 432Ω, 1%, 1/8W
700 15432034
R103, 104 Resistor, thick film, 10K, 1%, 1/8W 700 15100234
R107, 109 Resistor, thick film, 2K, 1%, 1/8W 700 15200134
R108, 110-112
Resistor, thick film, 562Ω, 1%, 1/8W
700 15562034
T101,10 2
Transformer, 2:1, 900µH
910 00100
TB2 Terminal block, 4 terminal 101126
U101 Integrated circuit, MOS D RTRG MNST MV, 74HC123 500 104
U102, 103 Opto device, 6N139 29592
U104 Integrated circuit, linear transformer driver, MAX845 510 107
U105, 109, 110 Integrated circuit, linear voltage regulator, 5V POS 0620 204
