RFL Electronics 9780 - Table 10-3. Replaceable Parts, RFL 9780 Output Filter Modules

RFL 9780 RFL Electronics Inc.
April 8, 2003 10-7 (973) 334-3100
Table 10-3. Replaceable parts, RFL 9780 Output Filter modules
30 to 67 kHz - Assembly No. 106530-1, -11
64 to 157 kHz - Assembly No. 106530-2, -12
154 to 393 kHz - Assembly No. 106530-3, -13
390 to 537 kHz - Assembly No. 106530-4, -14
114 to 288 kHz - Assembly No. 106530-5, -15
Circuit Symbol
(Figs. 10-3 & 10-4)
Description Part Number
CAPACITORS
C1 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.0715µF
0105 21
106530-2, -12: 0.033µF
0105 121
106530-3, -13: 0.014µF
0105 92
106530-4, -14: 0.0056µF
0105 112
106530-5, -15: 0.018µF
0105 83
C2 Capacitor, polypropylene, 2%, 100V
106530-, -11: 0.091µF
0105 23
106530-2, -12: 0.041µF
0105 81
106530-3, -13: 0.018µF
0105 83
106530-4, -14: 0.00715µF
0105 114
106530-5, -15: 0.024µF
0105 119
C3 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.00715µF
0105 114
106530-2, -12: 0.00315µF
0105 107
106530-3, -13: 0.0014µF
0105 104
106530-4, -14: 535pF 0105 101
106530-5, -15: 0.0018µF
0105 105
C4 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.036µF
0105 14
106530-2, -12: 0.017µF
0105 47
106530-3, -13: 0.00715µF
0105 114
106530-4, -14: 0.00285µF
0105 64
106530-5, -15: 0.0095µF
0105 76
C5 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.0285µF
0105 82
106530-2, -12: 0.013µF
0105 117
106530-3, -13: 0.0056µF
0105 112
106530-4, -14: 0.0022µF
0105 62
106530-5, -15: 0.0075µF
0105 73
C6 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.024µF
0105 119
106530-2, -12: 0.011µF
0105 30
106530-3, -13: 0.0047µF
0105 110
106530-4, -14: 0.0018µF
0105 105
106530-5, -15: 0.0062µF
0105 113
